Gorenje

Pyramid Hood, 60 cm

Freestanding wall chimney cooker hood

Product code: 745083 | Freestanding wall chimney cooker h | Max. noise level: 68 dB(A)re 1 pW | ood | Wall mounted cooker hood | Control setting: Button control | Maximum extraction rate by extraction operation: 680 m³/h | Energy class: A | Gorenje | Product line: G400 | Dimensions (W×H×D): 59.6 × 24 × 45.2 cm

Print
Share
Facebook X.com
Download
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
reestanding wall chimney cooker hood
Product Technical Details Support

Technical Details

  • Wall mounted cooker hood
  • Venting with air extraction or recirculation
  • Energy class: A
  • Material of housing/chimney: stainless steel / stainless steel
  • Colour of housing/chimney: stainless steel / stainless steel
  • Lightning efficiency class: A
  • Grease filtering efficiency class: D
  • Fluid dynamic efficiency class: A
  • Maximum extraction rate by extraction operation: 680 m³/h
  • Venting tube diameter: 15 cm
  • Air flow by extraction version, step 1: 272 m³/h
  • Air flow by extraction version, step 3: 680 m³/h
  • Mechanic control
  • Control setting: Button control
  • Number of speed positions: 3
  • Lamp type: LED
  • On/off light switch
  • Number of lights: 2
  • Filter material: Aluminium
  • Coal filter code (optional as separate purchase): 957982
  • Number of filters: 2
  • Number of charcoal filters: 2
  • Washable grease filter
  • Motor type: Capacitor motor
  • Number of motors: 1
  • No return airflow flap: 150 mm
  • Max. noise level: 68 dB(A)re 1 pW
  • Height: 240 mm
  • Min. height of the chimney: 695 mm
  • Max. height of the chimney: 880 mm
  • Annual energy consumption: 44.8 kWh
  • Dimensions (W×H×D): 59.6 × 24 × 45.2 cm
  • Dimensions of packed product (W×H×D): 65 × 30.5 × 53.8 cm
  • Net weight: 8.5 kg
  • Gross weight: 10.2 kg
  • Product code: 745083
  • EAN code: 3838782905315

Support

Installation drawing Product sheet
